MC-Montan Injekt TR-X

Soft-elastic hydrogel for injection of joints, soil and concrete components

Talk to a specialist ...

Properties

Very good injectivity due to low viscosity
Safe sealing due to high swelling ratio and high elasticity
Applicable in a wide range of temperature and at very low component temperatures
Easily adjustable injection paths and low consumptions due to short, variable reaction time
Corresponds to building material class B2 in the fire behaviour acc. to DIN 4102 in the injection medium
Fulfils the UBA guideline for seals in contact with drinking water
high chemical resistance even in highly alkaline environment
Waterproofing up to at least 7 bar water pressure
Particularly powerful due to polymer reinforcement and high solids content

Consolidation and sealing of fine and coarse loose soil - curtain injection
Extensive sealing injection between tunnel shell and sealing membranes
Elastic, swellable sealing of component joints (e.g. tunnel segments)
Sealing of cavities and imperfections in the area of the annular gap
Sealing of construction joints via injection hose systems
Injection of components with moisture content dry, moist, water-bearing during injection and with permanent at least one-sided water contact after injection
Elastic, swellable sealing injection into concrete components according to DIN EN 1504-5: U(S1) W (2/3/4) (1/40)
REACH-assessed exposure scenarios: long-term water-contact, periodical, application
